Anchor Insulator Connector

  • Filters
6 1/8" 75 ohm anchor insulator connector with anti-splitting device, silver plated. 1.5lbs.
+
6 1/8" 75 ohm adapter anchor insulator connector, silver plated. Used to connect 75 ohm industry standard to thin wall inner. 2lbs.
+
Adapter 6 1/8" 75 ohm line section. Inner Conductor has brand "D" thin wall inner conductor ID 1.661"on one end and industry standard wall ID 1.631" on the other end. 1.7lbs.
+
Adapter 6 1/8" 75 ohm expansion type anchor insulator connector, silver plated. Engineered to replace brand "D" expansion type anchor insulator. Slotted end mates with industry standard. Watchband end mates with brand "D" expansion type thin wall inner conductor assembly. 9.5lbs.
+
7 3/16" 75 Industry Standard ohm anchor insulator connector with anti-splitting device, silver plated. 2.66lbs.
+
8 3/16" 75 ohm Industry Standard anchor insulator connector with anti-splitting device, silver plated. 5.25lbs.
+
9 3/16" 50 ohm anchor insulator connector, silver plated. 8.8lbs.
+
